Circuit board processing that good

1. Familiar with the schematic diagram and structure diagram provided by hardware;

2. Set up the package and import the PCB. Conduct component layout according to the provided structure diagram, negotiate with the hardware about the general layout direction at the initial layout stage, and communicate with the hardware at any time during the layout process.

3. After the layout is OK, the hardware will confirm the layout and send it for preliminary confirmation.

4. Confirm stacking and start wiring

5, grasp the overall wiring direction, perfect signal line protection, power line pay attention to the size of the current, cutting power supply, copper, etc. Wiring does not understand at any time and hardware communication. 6. Send the wiring to the hardware for inspection in time, and modify the PCB according to the hardware requirements.

7. The hardware confirmed that there was no problem with the layout and sent it for check. 2D and 3D drawings of PCB layout. After confirming OK.

8. Send out Gerber file and write PCB production list.

9. Send PCB samples to the board factory and reply the engineering problems of the board factory.


1, the input end and the output end of the line should avoid parallel adjacent, so as to avoid interference. Grounding should be added when necessary, two adjacent layers of wiring should be vertical to each other, parallel easy to produce parasitic coupling.

2. Add decoupling capacitance between power supply and ground wire. It is better that the ground cable is wider than the power cable. The relationship between them is ground cable > power cable > signal cable. Usually, the width of signal cable is 0.2 ~ 0.3mm, and the width can reach 0.05 ~ 0.07mm

3, digital circuit and analog circuit common ground processing, digital circuit frequency is high, analog circuit sensitivity is strong, for the signal line, high frequency signal line as far as possible away from the sensitive analog circuit devices, for the ground wire, rectifier PCB to the outside only one node, so ** in the PCB internal processing number, mode common ground problem, And inside the board the digital and analog ground is actually separate and they are not connected to each other, only in the PCB and the external connection interface (such as plugs, etc.). There is a little bit of short circuiting between digital and analog, but note that there is only one connection point. There are also differences on the PCB, which is determined by the system design.

4. Shorten the connection between high-frequency components as far as possible, and try to reduce their distribution parameters and electromagnetic interference between each other. Easily disturbed components should not be too close to each other, input and output components should be as far away as possible. There may be a high potential difference between some components or wires. The distance between them should be increased to avoid accidental short circuit caused by discharge. Components with high voltage should be arranged as far as possible in places that are not easily touched by the hand during debugging.

5. For circuits working at high frequency, the distribution parameters between components should be considered. General circuits should be arranged as parallel as possible. In this way, not only beautiful. It is easy to assemble and weld. Easy to mass produce.

6. Input and output wires should be avoided as far as possible. It is better to add ground wire between lines to avoid feedback coupling.

7, printed wire bend generally take circular arc, and right Angle or included Angle in high frequency circuit will affect the electrical performance. If you must take a right Angle, generally use two 135 degrees to replace the right Angle.

8. Power cord design

According to the size of the printed circuit board current, try to rent the width of the power line, reduce the loop resistance. At the same time, the direction of the power cord and ground wire is consistent with the direction of data transmission, which helps to enhance the anti-noise capability.

9. Ground wire design

pcb

The principles of ground design are:

(1) digital and analog separation. If the circuit board contains both logical and linear circuits, keep them as separate as possible. Low frequency circuit should be as far as possible to use a single point of parallel grounding, the actual wiring difficulties can be partially connected after the parallel grounding. The high frequency circuit should be grounded in series at multiple points, the ground should be short and rented, and the high frequency element should be surrounded by a large area of grid foil as far as possible.

(2) The ground wire should be as thick as possible. If the grounding wire is very flexible line, the grounding potential changes with the change of current, so that the noise resistance performance is reduced. The ground wire should therefore be thickened so that it can pass through three times the allowable current on the printed board. If possible, the ground cable should be at least 2 mm to 3mm.

(3) The ground wire constitutes a closed-loop road. For printed boards composed only of digital circuits, the ground circuit is arranged into a group loop, which can improve the noise resistance.


10, lotus root capacitor configuration

One of the common practices of PCB design is to configure appropriate decommissioning capacitors in each key part of the printed board.

The general configuration principle of decommissioning capacitance is:

(1) The power input terminal is connected to an electrolytic capacitor of 10 ~100uf. If possible, use * above 100uF.

(2) In principle, each IC chip should be arranged with a 0.01pF ceramic capacitor. If the gap of the printed board is not enough, a 1-10pf capacitor can be arranged every 4-8 chips.

(3) For devices with weak anti-noise ability and large power supply changes when the device is turned off, such as RAM and ROM memory devices, the de-coupling capacitor should be directly connected between the power line and the ground wire of the chip.

(4) The capacitor lead should not be too long, especially the high-frequency bypass capacitor should not have a lead.


11. In addition, the following two points should be noted:

(1) When there are contactors, relays, buttons and other components in the printed board. Large spark discharges will be generated when operating them. ** The RC circuit shown in the attached figure is used to absorb the discharge current. Generally, R ranges from 1 to 2K and C ranges from 2.2 to 47UF.

(2)CMOS has a high input impedance and is susceptible to induction, so the unused end should be grounded or connected to a positive power supply when in use
