- PCB Design Capabilities
| PCB Design&Layout Capabilities | |||
| Min.trace width: | 2.5mil | Min.trace spacing | 2.5mil |
| Min.Vias: | 6mil(4mil laser drilling) | Max.layer | 48L |
| Min.BGA spacing | 0.35mm | Max.BGA Pin | 3600pin |
| Max.high-speed signal | 40 GBPS | Fastest delivery time | 6 Hours/ Item |
| HDI Highest layer | 22 L | HDI Highest layer | 14 L any layer HDI |
| PCB Design&Layout lead time | |||
| Number of pins on the board | 0-1000 | Design lead time (working days) | 3-5 days |
| 2000-3000 | 5-8 days | ||
| 4000-5000 | 8-12 days | ||
| 6000-7000 | 12-15 days | ||
| 8000-9000 | 15-18 days | ||
| 10000-12000 | 18-20 days | ||
| 13000-15000 | 20-22 days | ||
| 16000-18000 | 22-25 days | ||
| 18000-20000 | 25-30 days | ||
| Ultimate delivery capacity | 10000Pin/7 days | ||
| PS: The above delivery date is the regular delivery date, and the accurate design delivery date needs to be comprehensively evaluated according to the number of components, difficulty, layers and other factors of the circuit board! | |||
Kingford
Почему KINGFORD
Self-organized development
Self-developed tool software and strict quality control system to ensure a successful one-time board opening
difficult design
The maximum design scale is 90000pin, which can provide HDI/Any layer PCB design, 3D PCB design, RF design, 56G high-speed design, etc.
High-quality design quality system
With a strict quality system process and a strict review system, we have zero error rate quality requirements for PCB design.
Professional design team
PCB design team with an average of more than 12 years of work experience, with complete design software, such as Cadence Allegro\ORCAD, Mentor WG\PADS, etc.
Kingford
Отрасли, которые мы обслуживаем
Kingford
Impedance Control PCB Design FAQ
If the impedances do not match, the maximum power will not be delivered.
Impedance voltage can be reduced by reducing the number of turns in the low voltage winding and increasing the core window height.
Impedance affects how signals travel through the board, how power is transferred between components, and how signals penetrate into unwanted areas of the PCB.
What is Controlled Impedance? Controlled impedance is the characteristic impedance of the transmission line formed by the PCB traces and their associated reference planes.
